Horizantal Induction Heater
Product Code : GM 17
Brand Name : G M INDUSTRIES
Product Description
Horizantal Induction Heater GM12 ( Roll-Sliding Model )
With the assistance of our team of professionals, we are presenting a premium quality range of Induction Heating Machine. It is manufactured from world class components sourced from reliable sources of the industry with the help of high-end tools and technology. The entire range of Induction Heating Machine is known for optimum performance, high strength, smooth operation, rigid construction, easy installation, and durability. We offer this machine in various technical specifications as per the needs of clients.
With the assistance of our team of professionals, we are presenting a premium quality range of Induction Heating Machine. It is manufactured from world class components sourced from reliable sources of the industry with the help of high-end tools and technology. The entire range of Induction Heating Machine is known for optimum performance, high strength, smooth operation, rigid construction, easy installation, and durability. We offer this machine in various technical specifications as per the needs of clients.
TECHNICAL DATA SHEET
| Product Data | GM 12 |
| Power | 12 / 16 KVA |
| Voltage | 2 / 3 X 415V + 10% |
| Current (Max) | 32 / 40A |
| Power Control | 25% 50% 75% & 100% |
| Temperature Control (Range) | 0-250oC |
| Maximum Temperature | 400oC |
| Accuracy Temperature | + 3oC |
| Time-Control | 0-99 Minutes |
| Residual Magnestium | <1A / cm |
| Overall dimensions (wxdxh) (mm) | 590 X 330 X 480 |
| Space between supports (wxh) (mm) | 320 X 205 |
| Weight (Main Unit) | 90 Kg. |
| Weight with Standard Yokes | 115 Kg |
| Horizontal York Sizes (mm) | 80 X 80 X 500 for bore dia. 112 MM & above |
| Colour of the Equipment | RED / BLUE & APPLE GREEN |
Optional Accessories
| Horizontal Yoke Sizes (mm) | 30 X 30 X 500 for bore dia. |
| 40 X 40 X 500 for bore dia. | |
| 50 X 50 X 500 for bore dia. | |
| 65 X 65 X 500 for bore dia. | |
| Digital Thermometer (0-500 C) | Yes |
| Roll-Sliding Model | Yes |
| Swing Arm Model | Yes |
| Riser Block (Pair) (mm) | ----- |
| Magnetic Temperature Probe | Yes |
| Equipment Trolley | Yes |
| Hydraulic Equipment Trolley | Yes |
| Hydraulic Stacker for loading & unloading of Component | Yes |
